MINIMAX 3-SECTION 450-950

The MINIMAX roller is an all-round roller that can be used for many purposes. It has been produced since the 1980's, and to this day it is our best selling model with a state-of-the-art design.

Minimax Kopi
Working width
4,50-9,50 m
Transport width
2,50-3,00 m
Ring size
50-60 cm
Horsepower
> 50
Weight
1.860-6.410 kg
MINIMAX

DALBO MINIMAX

MINIMAX Talkover

DALBO MINIMAX presentation

Technical data

MINIMAX 450

Transport width
2,30 m
SNOWFLAKE® 50 cm weight/number of rings
2.190 kg/91 pcs.
SNOWFLAKE® 55 cm weight/number of rings
2.610 kg/91 pcs.
SNOWFLAKE® 60 cm weight/number of rings
-
Crosskill 53 cm weight/number of rings
1.860 kg/45 pcs.
Cross Combi 50 cm weight/number of rings
2.230 kg/78 pcs.
Cross Combi 55 cm weight/number of rings
-
Wheels
260/75x15.3
Min. power requirements
50 HP
Hydraulic connections
1xDA, 1xSA

MINIMAX 530

Transport width
2,50 m
SNOWFLAKE® 50 cm weight/number of rings
2.800 kg/109 pcs.
SNOWFLAKE® 55 cm weight/number of rings
3.290 kg/109 pcs.
SNOWFLAKE® 60 cm weight/number of rings
-
Crosskill 53 cm weight/number of rings
2.325 kg/55 pcs.
Cross Combi 50 cm weight/number of rings
2.740 kg/94 pcs.
Cross Combi 55 cm weight/number of rings
-
Wheels
260/75x15.3
Min. power requirements
75 HP
Hydraulic connections
1xDA, 1xSA

MINIMAX 630

Transport width
2,50 m
SNOWFLAKE® 50 cm weight/number of rings
3.145 kg/129 pcs.
SNOWFLAKE® 55 cm weight/number of rings
3.720 kg/129 pcs.
SNOWFLAKE® 60 cm weight/number of rings
4.515 kg/129 pcs.
Crosskill 53 cm weight/number of rings
2.660 kg/63 pcs.
Cross Combi 50 cm weight/number of rings
3.215 kg/114 pcs.
Cross Combi 55 cm weight/number of rings
3.740 kg/114 pcs.
Wheels
300/80 x15,3
Min. power requirements
100 HP
Hydraulic connections
1xDA, 1xSA

MINIMAX 760

Transport width
2,50 m
SNOWFLAKE® 50 cm weight/number of rings
4.070 kg/157 pcs.
SNOWFLAKE® 55 cm weight/number of rings
4.760 kg/157 pcs.
SNOWFLAKE® 60 cm weight/number of rings
-
Crosskill 53 cm weight/number of rings
3.545 kg/79 pcs.
Cross Combi 50 cm weight/number of rings
4.160 kg/134 pcs.
Cross Combi 55 cm weight/number of rings
4.940 kg/134 pcs.
Wheels
300/80x15.3 Twin
Min. power requirements
110 HP
Hydraulic connections
1xDA, 1xSA

MINIMAX 830

Transport width
2,50 m
SNOWFLAKE® 50 cm weight/number of rings
4.160 kg/165 pcs.
SNOWFLAKE® 55 cm weight/number of rings
4.930 kg/165 pcs.
SNOWFLAKE® 60 cm weight/number of rings
5.875 kg/165 pcs.
Crosskill 53 cm weight/number of rings
3.650 kg/83 pcs.
Cross Combi 50 cm weight/number of rings
4.310 kg/142 pcs.
Cross Combi 55 cm weight/number of rings
5.095 kg/138 pcs.
Wheels
300/80x15.3 Twin
Min. power requirements
120 HP
Hydraulic connections
1xDA, 1xSA

MINIMAX 950

Transport width
3,00 m
SNOWFLAKE® 50 cm weight/number of rings
5.215 kg/189 pcs.
SNOWFLAKE® 55 cm weight/number of rings
6.090 kg/ 189 pcs.
SNOWFLAKE® 60 cm weight/number of rings
-
Crosskill 53 cm weight/number of rings
4.580 kg/95 pcs.
Cross Combi 50 cm weight/number of rings
5.340 kg/160 pcs.
Cross Combi 55 cm weight/number of rings
6.410 kg/160 pcs.
Wheels
400/60x15.5 Twin
Min. power requirements
130 HP
Hydraulic connections
1xDA, 1xSA
TA Minimax 6.3
Concept

With a MINIMAX, we deliver a precise and high-performance quality roller

It handles all roller tasks before and after sowing and can also be used as a packer for a stubble or seedbed preparation.

MINIMAX is our smallest hydraulic folding roller, but still offers you all the usability, performance and versatility of our larger models. The tractor driver can perform the entire folding and unfolding of the roller sections from inside the tractor and without the need for further manoeuvring, which is both practical and safe. All MINIMAX rollers have our well-known DUOFLEX system.


The heavy duty springs ensure an evenly distributed ground pressure plus an individual flexibility that allows each section to follow changing field contours and irregularities.

The packing capacity of the roller is ensured in full working width via the large overlap between each section, which provides full-width ground contact, even when turning and working on uneven fields.

Most MINIMAX models can be equipped with a hydraulically operated cracker board, making it a great tool for seedbed preparation. In summary, a MINIMAX is a unique combination of value and versatility.

Standard equipment

MINIMAX standard equipment

  • Fully hydraulic folding and unfolding of sections. Switching from
    driving on roads to field operation without leaving the tractor.
  • Ø60 mm shafts made of high-tensile steel.
  • Strong frames made of quality steel and high-tensile steel.
  • Automatic weight distribution with springs that ensure an
    evenly distributed ground pressure is ensured across the full working width, regardless of the contours of the soil.
  • DUOFLEX with individual flexibility between sections.
  • Hydraulic weight distribution on 950 model.
  • Automatic transport security for optimal safety during transport.
  • SNOWFLAKE® rings with a 6 year warranty.
  • Detachable support legs.
  • Hydraulic connections: 1xSA and 1xDA.
TA Minimax6.3M

Roller rings

SNOWFLAKE®. This ring is used in combination with a breaker ring and is suitable for most purposes, both before and after sowing

It is especially suitable for the care of grasslands as well as use together with the hydraulic cracker board for levelling cloddy soils.

The Cross Combi rings are very suitable for seedbed preparation and rolling of grasslands. The Crosskill ring type is used primarily for seedbeds and leaves the soil loose on top.

MINIMAX Lamelplanke

Cracker board

Hydraulically operated and adjustable cracker board, consisting of strong 80 mm spring tines with 200 x 12 mm swaged wearing parts.

This makes it perfect for crushing tubers and levelling the soil, thus leaving the soil loose, smooth and in perfect condition for the roller section.

When using only MINIMAX for rolling, the cracker board can be lifted hydraulically, providing increased usability and versatility.

The cracker board requires an extra double-acting hydraulic outlet on the tractor. In order to achieve optimal working conditions for, and thereby the effect of, the cracker board, we  recommend a working speed of 8-10 km per hour.

Accessories and extra equipment

  • Air brakes or hydraulic brakes
  • High pull, drawbar or Scharmüller ball hitch
  • LED lighting
  • Wheel track erradicator
  • Hydraulic weight distribution on 950
  • Track marking
  • Wheel upgrade 530-950
  • Rubber Suspended bearings on roller shafts 530-950
  • Stone tray option 45L or 100L 530-950
  • Hydraulic cracker board
  • Hydraulic jack on 630-760
  • DALBO seeder for 630-950
